SKU:CS-610-75

Greystone CS-610-75 AC Current Switch, Mini solid core 30 Vac/dc switch, MOSFET, 0.75 - 75 amps, status LED

Greystone CS-610-75 AC Current Switch, Mini solid core 30 Vac/dc switch, MOSFET, 0.75 - 75 amps, status LED

Regular price $57.85 USD
Regular price Sale price $57.85 USD
Sale
Shipping calculated at checkout.

Greystone CS-610-75 is a mini AC current switch with a trip point adjustable from 0.75 to 75 A using the adjustment potentiometer. The normally open solid-state MOSFET output closes when monitored current exceeds the trip setpoint, providing an on/off signal rather than a proportional analog current measurement. A status LED illuminates when the trip-point setting is reached.

The sensor is self-powered by induction from the monitored AC line and requires no external power supply. Maximum continuous input current is 75 A at 50/60 Hz. The output switch rating is 30 Vac/dc, 500 mA maximum, separate from monitored-current capacity. Typical response time is 200 ms.

Mounting tabs secure the device inside a motor control panel using two #10 screws. The sensor uses a two-wire connection to the building automation system. Screw terminals accept 14-22 AWG wiring, with a published terminal torque rating of 0.5 Nm. Use insulated conductors only; the insulation class is 600 Vac. Follow manufacturer installation instructions and applicable electrical safety procedures.

The sensing aperture is 11.4 mm (0.45 in), and specification-table dimensions are 48 x 49 x 21 mm (1.9 x 1.93 x 0.83 in). Enclosure material is ABS/polycarbonate with a UL94-V0 material rating. Operating conditions are -15 to 60 C (5-140 F) and 5-90% RH, non-condensing.

Applications include AC load-status monitoring for pumps, conveyors, lighting, heaters and fans. Current presence alone does not establish mechanical performance or identify a specific fault.
