SKU:CS-GNG-100

Greystone CS-GNG-100 Mini solid core 30 Vac/dc switch, MOSFET, Go - No - Go, 0.5 - 100 amps, 0.5 amp trip

Greystone CS-GNG-100 Mini solid core 30 Vac/dc switch, MOSFET, Go - No - Go, 0.5 - 100 amps, 0.5 amp trip

Regular price $44.91 USD
Regular price Sale price $44.91 USD
Sale
Shipping calculated at checkout.

Greystone CS-GNG-100 is a mini AC current switch for Go/No Go load-status monitoring. Its factory-set trip point is specified at 0.5 A or less. The normally open solid-state MOSFET output closes when monitored current exceeds the trip setpoint, providing an on/off signal to a controller rather than a proportional analog current measurement.

The sensor is self-powered by induction from the monitored AC line and requires no external power supply. Maximum continuous input current is 100 A. It operates at 50/60 Hz with a typical response time of 200 ms. The output switch rating is 30 Vac/dc, 500 mA maximum, separate from monitored-current capacity. This model has a fixed trip point, not an adjustable 0.5-100 A trip range.

Mounting tabs secure the device inside a motor control panel using two #10 screws. The sensor uses a two-wire connection to the building automation system, and screw terminals accept 14-22 AWG wiring. Use insulated conductors only; the published insulation class is 600 Vac. Follow manufacturer installation instructions and applicable electrical safety procedures.

The sensing aperture is 11.4 mm (0.45 in), and specification-table dimensions are 48 x 49 x 21 mm (1.9 x 1.93 x 0.83 in). Enclosure material is ABS/polycarbonate with a UL94-V0 material rating. Operating conditions are -15 to 60 C (5-140 F) and 5-90% RH, non-condensing.

Applications include status monitoring for pumps, conveyors, lighting, heaters and fans. Current presence alone does not establish mechanical performance or identify a specific fault.
