Senva HT1R-3KUX Recessed Wall RH Sensor, 3% RH, No LCD, 20K ohm thermistor
Senva HT1R-3KUX Recessed Wall RH Sensor, 3% RH, No LCD, 20K ohm thermistor
Couldn't load pickup availability
The Senva HT1R-3KUX is an HT1R recessed-wall humidity sensor with +/-3% RH specified accuracy over 0-100% RH and no LCD display. This configuration includes a 20K ohm thermistor as its separate passive temperature option, not the temperature-transmitter option.
The U universal output supports selectable 0-5 V, 0-10 V, or 4-20 mA, with 2-wire and 3-wire modes as specified in the installation instructions. RH output scaling is 0-100% RH, non-condensing. The 0-10 V output requires 15-30 VDC or 24 VAC. The datasheet lists a 12-30 VDC or 24 VAC supply, 100 mA maximum.
On-board temperature compensation supports RH measurement. The RH element normal operating conditions are 5-60 degrees C at 20-80% RH; prolonged exposure to high humidity outside normal conditions may temporarily offset RH readings. No NIST calibration option is selected in this part number. The recessed housing provides a low-profile installation without exposed screws. The PTFE media filter has IP54 protection; this is not a whole-enclosure IP54 rating.
Product Features
- Recessed Wall RH sensor
- +/-3% RH specified accuracy over 0-100% RH
- No LCD display
- 20K ohm thermistor
- U universal output: 0-5 V, 0-10 V, or 4-20 mA
- 0-100% RH output scaling; non-condensing
- On-board temperature compensation for RH
- 10 V output requires 15-30 VDC or 24 VAC
- Low-profile recessed housing
