SKU:2301001PD2F2DB

Setra 2301001PD2F2DB Wet-to-Wet Differential Pressure Transducer, 0 to 1 PSID, 0-5 VDC

Setra 2301001PD2F2DB Wet-to-Wet Differential Pressure Transducer, 0 to 1 PSID, 0-5 VDC

Regular price $730.08 USD
Regular price Sale price $730.08 USD
Sale
Shipping calculated at checkout.

The Setra 2301001PD2F2DB is a Model 230 wet-to-wet differential pressure transducer configured for unidirectional measurement from 0 to 1 PSID. It provides a 0-5 VDC output and includes 1/4-18 NPT female pressure fittings. This configuration uses Viton bleed screw seals.

The Model 230 uses a single-diaphragm, stainless steel capacitive sensor and is specified for +/-0.25% FS accuracy at constant temperature. Its NEMA 4-rated housing and conditioned analog output support differential pressure monitoring in HVAC and process-control applications. Media must be compatible with the sensor and, where fitted, manifold materials.

Product Features

  • Unidirectional differential pressure range: 0 to 1 PSID
  • 0-5 VDC output
  • 1/4-18 NPT female pressure fittings
  • Viton bleed screw seals
  • Single-diaphragm stainless steel capacitive sensor
  • +/-0.25% FS accuracy at constant temperature
  • NEMA 4-rated housing
