SKU:2691R25WB11DNVA

Setra 2691R25WB11DNVA Low Differential Pressure Transducer, +/-0.25 in WC, 4-20 mA, +/-0.25% FS, 2:1 Turndown

Setra 2691R25WB11DNVA Low Differential Pressure Transducer, +/-0.25 in WC, 4-20 mA, +/-0.25% FS, 2:1 Turndown

Regular price $1,026.62 USD
Regular price Sale price $1,026.62 USD
Sale
Shipping calculated at checkout.

The Setra 2691R25WB11DNVA is a Model 269 low differential pressure transducer for air or similar non-conducting gases. This configuration measures +/-0.25 in WC and provides a 2-wire, 4-20 mA output with +/-0.25% FS accuracy at constant temperature. It includes a 35 mm DIN rail mount configuration and no display. The specified configuration includes 2:1 turndown. A calibration certificate is included as standard.

The removable process head has 3/16-inch O.D. barbed brass pressure fittings, and the detachable screw-terminal connector supports servicing without cutting the pressure tubing. Zero and span adjustments require the separate security calibration key, part number 269425-02. The Model 269 is designed for critical-environment differential pressure monitoring, including clean rooms, isolation rooms, and room pressure applications.

Product Features

  • Pressure range: +/-0.25 in WC
  • 2-wire, 4-20 mA output
  • +/-0.25% FS accuracy at constant temperature
  • 35 mm DIN rail mount
  • No display
  • 2:1 turndown
  • Calibration certificate included as standard
  • Removable process head with 3/16-inch O.D. barbed brass fittings
  • For air or similar non-conducting gases
